Description
Product Highlights
4-STROKE, DOHC, 4-VALVE, 6-SPEED
Vertically Stacked LED Headlights
Tail Light and LED License Plate Light
Tubeless Tires with 10-spoke Cast Wheels
Shutter Key Lock
Sporty Separated Seat Design
Suzuki Easy Start System
Decent Steering Angle
Specifications
Engine
Type : Twincam 4 Valve, DOHC, 4 Stroke
Cooling System : Liquid Cooled
Bore x Stroke : 62.0 x 48.8 mm
Displacement : 147 cc
Ignition System : Electronic Transistorized
Compression Ratio : 11.5 : 1
Carburetion : Fuel Injection
Starter System : Electric
Lubrication System : SJCS (Suzuki Jet Cooling System)
Transmission
Clutch System : Wet Sump
Transmission : 6 Speed Constant Mesh
Chassis
Suspension Front : Telescopic, Coil Spring, Oil Damped
Suspension Rear : Mono Shock with Swingarm (Link Type)
Brake Front : Disc Brake
Brake Rear : Disc Brake
Tire Size Front : 90/80-17M/C 46P (Tubeless)
Tire Size Rear : 130/70-17M/C 62P (Tubeless)
Wheel Type : Cast Wheel
Fuel : Gasoline or Gasohol 91 Octane Up
Fuel Tank Capacity : 11.0 Liter
Dimensions
Width x Length x Height : 745 x 2,000 x 1,035 mm
Full Weight : 133 kg
Wheelbase : 1,300 mm
Seat Height : 785 mm
Caster/Trail : 26 / 93 mm
Ground Clearance : 155 mm
